The All-in-One Solar Inverter Series integrates a pure sine wave inverter and MPPT solar charge controller into one compact system. Designed for off-grid and backup power applications, the series offers multiple power and charging configurations to meet different solar energy system requirements.
Available in 1300W, 2300W, 3300W and 4000W inverter models with 30A, 60A or 100A MPPT solar charging. Battery voltage options include 12V, 24V and 48V, with a maximum PV input voltage of 145V. This series is designed for solar and battery operation and does not support utility/grid AC input or AC charging.
Key Features：
- 1300W / 2300W / 3300W / 4000W inverter options
- 30A / 60A / 100A MPPT solar charging
- 12V / 24V / 48V battery voltage options
- Maximum PV input voltage: 145V
- Pure sine wave AC output
- Integrated inverter + MPPT solar charge controller
- No utility/grid AC input
- No AC charging function
- Multiple protection functions
- Suitable for off-grid and backup power systems
- OEM/ODM specifications available for different markets
Specification Details Model Options 1300W / 30A MPPT; 2300W / 60A MPPT; 3300W / 60A MPPT; 3300W / 100A MPPT; 4000W / 100A MPPT Inverter Power 1300W / 2300W / 3300W / 4000W MPPT Charging Current 30A / 60A / 100A Battery Voltage Options 12V / 24V / 48V Max. PV Input Voltage 145V DC Output Waveform Pure Sine Wave Utility / Grid AC Input Not Supported AC Charging Not Supported System Type Inverter + MPPT Solar Charge Controller Applications Off-Grid / Backup Power Systems
